2.5"F / 2"R SST Lift Kit - Honda Pilot 2016-2021

$379.95
In stock
SKU
69-8620

2.5"/2" SST lift kit for 2016-2020 Honda Pilot. Premium bolt-on lift solution. Provides improved ground clearance and the ability to install larger wheels and tires. Ideal for the Pilot owner who wants to increase the adventurous opportunities that a lift kit and larger tires can provide in off road environments. Maintains all factory safety feature performance.

Have a question? Please call 800-549-4620

TIRE/WHEEL SIZING GUIDE

  • ReadyLIFT offers 2016-2020 Honda Pilot AWD owners a great lift solution. Our all-new 69-8620 SST lift kit is an ideal choice for improving the ground and tire clearance of Honda's popular mid-size CUV. Using our very popular and easy-to-install application specific offset spacer design, this new Honda Pilot lift kit provides 2.5" of front lift and 2" of rear lift. 69-8620 includes premium heavy-duty steel front strut spacers with longer front sway bar end links. The rear features CNC-machined billet Aluminum rear spacers and includes unique rear cradle drop spacers that help dial in the proper alignment geometry. Our new ReadyLIFT Honda Pilot SST lift kit increases overall ground clearance while allowing for upgrading to a larger off-road style tire to improve the overall adventurous spirit. Honda was gracious enough to make the fender well opening noticeably larger on the Honda Pilot and we found that you can fit up to a 265/60R18 tire on a 18x9 +35 offset wheel that fits comfortably with no rubbing issues. Easy installation. Does not interrupt the factory safety features. Provides 2.5" front and 2" rear lift. Allows for up to a 265/60-18 tire on a 9" wide wheel.
  • Max: 265/60R18 tire on a 18x9 +35 offset wheel

    Tire Size Note: ReadyLIFT wheel and tire fitment recommendations are typically based on Wheel Pros wheels and Nitto tires. Due to product differences among tire manufacturers, tire specifications and dimensions including, but limited to, overall diameter, rolling diameter, tread width, aspect ratio, lug pattern, sidewall construction and inflation pressure, will vary meaningfully by tire and wheel manufacturer. Every tire and wheel combination should be test fit prior to installation. Consult your local installer to learn more about the right tire fitment for your application.

    Ride Quality Note: When lifting a vehicle and installing aftermarket wheels and tires, a tire manufacturer's construction and material quality can alter vehicle ride quality. When increasing a vehicle wheel and tire size, most larger aftermarket truck and SUV tires are 10-ply (or more) E tires compared to typical OEM 6-ply C tires. This more rigid sidewall construction increases the perception of suspension stiffness often described as ride harshness. The ride, handling, traction, noise, fuel economy, and wear differences between All-Season, All-Terrain, Mud-Terrain, or Trail-Terrain type tires can be significant. Please take into account tire and wheel choice will generally have a meaningful impact on the ride & handling experience.

  • Front offset strut spacers

    Rear spacers and cradle drop spacers

    Longer front end links

  • SAEJ2492 WARNING: By installing this product, you acknowledge that the suspension of this vehicle has been modified. As a result, this vehicle may handle differently than factory-equipped vehicles. As with any vehicle, extreme care must be used to prevent loss of control or rollover during sharp turns or abrupt maneuvers. Always wear seat belts, and drive safely, recognizing that reduced speeds and specialized driving techniques may be required. Failure to drive this vehicle safely may result in serious injury or death. Do not drive this vehicle unless you are familiar with its unique handling characteristics and are confident of your ability to maintain control under all driving conditions. Some modifications (and combinations of modifications) are not recommended and may not be permitted in your state. Consult your owner's manual, the instructions accompanying this product, and state laws before undertaking these modifications. You are responsible for the legality and safety of the vehicle you modify using these components.



    INSTALLATION ALIGNMENT NOTE:  Your vehicle may require alignment after product installation.  You may incur additional costs to align the vehicle.



    INSTALLATION HEADLAMP AIM NOTE:  In addition to your vehicle alignment, for your safety and others, it is necessary to check and adjust your vehicle headlamps for proper aim and alignment after product installation.  You may incur additional costs to adjust the headlamp system.



    INSTALLATION ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS) NOTE:  If your vehicle is equipped with active or passive safety/collision monitoring and/or assistance/avoidance systems including, but not limited to, camera- or radar/sonar-based systems, check and adjust your vehicle’s systems for proper aim and function after product installation.   In some instances, your vehicle may require OEM dealer service tools and factory-trained technicians to re-calibrate ADAS.  You may incur additional costs to adjust ADAS systems.


    DO IT YOURSELF: Please read Instructions thoroughly and completely before beginning installation. Installation by a certified mechanic is recommended. ReadyLIFT Suspension Inc. is NOT responsible for any damage or failure resulting from improper installation. Download Pdf Instructions

    Have a certified mechanic do it for you!


Quick Overview
2.5"/2" SST lift kit for 2016-2020 Honda Pilot. Premium bolt-on lift solution. Provides improved ground clearance and the ability to install larger wheels and tires. Ideal for the Pilot owner who wants to increase the adventurous opportunities that a lift kit and larger tires can provide in off road environments. Maintains all factory safety feature performance.
Details
ReadyLIFT offers 2016-2020 Honda Pilot AWD owners a great lift solution. Our all-new 69-8620 SST lift kit is an ideal choice for improving the ground and tire clearance of Honda's popular mid-size CUV. Using our very popular and easy-to-install application specific offset spacer design, this new Honda Pilot lift kit provides 2.5" of front lift and 2" of rear lift. 69-8620 includes premium heavy-duty steel front strut spacers with longer front sway bar end links. The rear features CNC-machined billet Aluminum rear spacers and includes unique rear cradle drop spacers that help dial in the proper alignment geometry. Our new ReadyLIFT Honda Pilot SST lift kit increases overall ground clearance while allowing for upgrading to a larger off-road style tire to improve the overall adventurous spirit. Honda was gracious enough to make the fender well opening noticeably larger on the Honda Pilot and we found that you can fit up to a 265/60R18 tire on a 18x9 +35 offset wheel that fits comfortably with no rubbing issues. Easy installation. Does not interrupt the factory safety features. Provides 2.5" front and 2" rear lift. Allows for up to a 265/60-18 tire on a 9" wide wheel.
Tire Fitment

Max: 265/60R18 tire on a 18x9 +35 offset wheel

Tire Size Note: ReadyLIFT wheel and tire fitment recommendations are typically based on Wheel Pros wheels and Nitto tires. Due to product differences among tire manufacturers, tire specifications and dimensions including, but limited to, overall diameter, rolling diameter, tread width, aspect ratio, lug pattern, sidewall construction and inflation pressure, will vary meaningfully by tire and wheel manufacturer. Every tire and wheel combination should be test fit prior to installation. Consult your local installer to learn more about the right tire fitment for your application.

Ride Quality Note: When lifting a vehicle and installing aftermarket wheels and tires, a tire manufacturer's construction and material quality can alter vehicle ride quality. When increasing a vehicle wheel and tire size, most larger aftermarket truck and SUV tires are 10-ply (or more) E tires compared to typical OEM 6-ply C tires. This more rigid sidewall construction increases the perception of suspension stiffness often described as ride harshness. The ride, handling, traction, noise, fuel economy, and wear differences between All-Season, All-Terrain, Mud-Terrain, or Trail-Terrain type tires can be significant. Please take into account tire and wheel choice will generally have a meaningful impact on the ride & handling experience.

Kit Components

Front offset strut spacers

Rear spacers and cradle drop spacers

Longer front end links

Installation

SAEJ2492 WARNING: By installing this product, you acknowledge that the suspension of this vehicle has been modified. As a result, this vehicle may handle differently than factory-equipped vehicles. As with any vehicle, extreme care must be used to prevent loss of control or rollover during sharp turns or abrupt maneuvers. Always wear seat belts, and drive safely, recognizing that reduced speeds and specialized driving techniques may be required. Failure to drive this vehicle safely may result in serious injury or death. Do not drive this vehicle unless you are familiar with its unique handling characteristics and are confident of your ability to maintain control under all driving conditions. Some modifications (and combinations of modifications) are not recommended and may not be permitted in your state. Consult your owner's manual, the instructions accompanying this product, and state laws before undertaking these modifications. You are responsible for the legality and safety of the vehicle you modify using these components.



INSTALLATION ALIGNMENT NOTE:  Your vehicle may require alignment after product installation.  You may incur additional costs to align the vehicle.



INSTALLATION HEADLAMP AIM NOTE:  In addition to your vehicle alignment, for your safety and others, it is necessary to check and adjust your vehicle headlamps for proper aim and alignment after product installation.  You may incur additional costs to adjust the headlamp system.



INSTALLATION ADVANCED DRIVER ASSISTANCE SYSTEMS (ADAS) NOTE:  If your vehicle is equipped with active or passive safety/collision monitoring and/or assistance/avoidance systems including, but not limited to, camera- or radar/sonar-based systems, check and adjust your vehicle’s systems for proper aim and function after product installation.   In some instances, your vehicle may require OEM dealer service tools and factory-trained technicians to re-calibrate ADAS.  You may incur additional costs to adjust ADAS systems.



DO IT YOURSELF: Please read Instructions thoroughly and completely before beginning installation. Installation by a certified mechanic is recommended. ReadyLIFT Suspension Inc. is NOT responsible for any damage or failure resulting from improper installation. Download Pdf Instructions

Have a certified mechanic do it for you!
